The XT30 male connector is a two-pin DC power connector rated for up to 30 A continuous current. It is built for drones, RC models, LED and power modules, sensors and controllers. On electric bikes and scooters, it serves auxiliary 5–30 A branches rather than the main battery line. Quantity supplied: 1 piece.
This is a solder-type connector half, not a cable or an adapter. The pins are soldered directly to your wire, which gives a tidy joint with low resistance. Solder tabs accept 14–18 AWG wire, so the conductor size is clearly defined. The matching XT30 female socket is sold separately.
Contacts are made from gold-plated copper alloy, and the housing is heat-resistant PA/nylon. Keyed, asymmetrical geometry prevents reversed polarity during assembly. XT30 is the smallest of the three main XT-series connectors, so it fits builds where an XT60 or XT90 simply would not.
Key Benefits
- Up to ~30 A continuous current – enough for most compact RC and DIY devices.
- Gold-plated copper alloy contacts – low contact resistance and reduced voltage drop.
- Keyed asymmetrical geometry – physically blocks reversed polarity connections.
- Heat-resistant PA/nylon housing – withstands soldering heat and working temperatures.
- Small size and low weight – fits where XT60 or XT90 connectors will not.
- Solder tabs for 14–18 AWG wire – a defined conductor range with no improvising.
- Two-pin DC layout – a simple, unambiguous positive and negative arrangement.
- Sold as 1 piece – order exactly as many connectors as your project needs.
Who Is This Connector For?
The XT30 male connector is widely used in drones and RC models, where weight and available space are limiting factors. Builders also fit it to LED strips and power modules, as well as to sensors and controllers. In each case, the compact body keeps the wiring harness tight.
On electric bikes and electric scooters, this connector belongs on auxiliary 5–30 A branches. High-power main battery lines call for XT60 or XT90 instead. Therefore, choose XT30 for lighting circuits, control wiring and sensor-based branches.
Furthermore, the connector suits prototypes and bench power supplies. The male half with exposed pins is normally fitted to the de-energised side. In practice, that means the speed controller, the load, or a charger output.
Package Contents
- XT30 male connector – 1 pc.
- Matching XT30 female connector – sold separately.
Technical Specifications
| Type | XT30 male, 2 pins (DC) |
|---|---|
| Rated continuous current | ≈ 30 A |
| Recommended wire gauge | 14–18 AWG |
| Contacts | Gold-plated copper alloy |
| Housing | PA / nylon, heat resistant |
| Polarity protection | Keyed, asymmetrical geometry |
| Anti-spark | None |
| Mounting | Soldered to wire |
| Quantity | 1 pc. |
Installation Tips
- Observe polarity and confirm the pin arrangement before soldering.
- Use a soldering iron with sufficient thermal power, then solder briefly.
- Slide heat-shrink tubing over each joint after soldering.
- Leave a strain relief loop in the cable near the connector.
Why Choose the XT30 Male Connector?
The main difference from XT60 comes down to dimensions. XT30 is smaller and lighter, so it is intended for lower currents. XT60 handles roughly 60 A, while XT90 handles around 90 A. In a compact drone or a sensor circuit, that size gap often decides whether the joint fits at all.
Second, the gold-plated copper alloy contacts maintain steady mating pressure and low resistance. As a result, heating drops at higher currents. Real-world capacity still depends on wire gauge, cable length, cooling and solder quality.
Third, the keyed geometry is more than a styling detail. It physically prevents mating the halves backwards. Consequently, the risk of a short circuit during assembly falls noticeably.
Frequently Asked Questions
Is the XT30 male connector suitable for drones and RC models?
- Yes, this is one of its primary uses.
- It is rated for up to ~30 A continuous current.
- That covers most compact RC and drone builds.
- Its low weight also helps on small airframes.
Can I use it on an electric bike or scooter?
- Yes, on auxiliary 5–30 A branches.
- Typical examples include lighting and sensor circuits.
- Main battery lines should use XT60 or XT90.
What wire gauge should I solder to it?
- The solder tabs are sized for 14–18 AWG wire.
- Thicker wire will not seat correctly in the tabs.
- Cable length and cooling also affect real current capacity.
Does the connector include anti-spark protection?
- No, this version has no anti-spark feature.
- Connect and disconnect it on a de-energised circuit.
Is the female half included?
- No, only the male connector is supplied.
- Quantity is 1 piece.
- The matching XT30 female socket is ordered separately.
How does XT30 compare with XT60 and XT90?
- XT30 is rated at roughly 30 A.
- XT60 handles about 60 A, XT90 about 90 A.
- XT30 is the smallest and lightest of the three.
Where should the male half be installed?
- Fit it on the side that is not energised.
- Common positions are the speed controller, the load, or a charger output.
- Cover the finished joint with heat-shrink tubing.
With gold-plated copper alloy contacts, a heat-resistant PA/nylon body and keyed polarity protection, this XT30 male connector gives compact builds a reliable 30 A power joint. Solder it to 14–18 AWG wire, protect the joint, and pair it with an XT30 female socket to complete the link.
