The 60V 84Ah SurRon battery is a custom-built lithium-ion pack that delivers 16 kW of burst power. It is designed specifically for SurRon electric dirt bikes running upgraded controllers. Compatible controllers include the ASI BAC4000, ASI BAC8000, Torp TC500, EBMX X9000 and KO Moto. Nominal voltage is 60V and rated capacity is 84 Ah.
Every pack is assembled from Samsung cells. The cell groups are joined with genuine copper plates instead of standard nickel strips. A rigid metal housing protects the cells from impacts and debris on the trail. Integrated temperature sensors monitor the pack continuously during riding and charging.
This pack suits riders who have already upgraded their SurRon electronics and now want more range and torque. Range and power increase by up to three times compared with a stock setup. Connecting this battery to the original SurRon controller is strictly prohibited. Therefore, the bike must be fitted with a more powerful controller before installation.
Key Benefits
- Genuine copper plates – cell connections use copper plates rather than the usual nickel strips.
- Lower cell imbalance – better contact between cells reduces voltage drift across cell groups.
- Cooler operating temperature – copper connections mean less heat build-up, so the pack lasts longer.
- Samsung cells – the entire pack is built from Samsung-manufactured lithium-ion cells.
- 16 kW burst power – instantaneous maximum output reaches 16,000 W.
- 84 Ah capacity – large capacity supports long off-road and enduro sessions.
- Rugged metal housing – a solid metal case shields the cells from external damage.
- Integrated temperature sensors – dedicated hardware prevents the pack from overheating.
- Charging protection – charging is blocked when the pack is too cold or too hot.
- Bluetooth app monitoring – your phone shows pack status, plus the voltage and temperature of every cell group.
Who Is This Battery For?
This 60V 84Ah pack is built for SurRon electric bikes fitted with an upgraded controller. Supported controllers are the ASI BAC4000, ASI BAC8000, Torp TC500, EBMX X9000 and KO Moto. It also works with other SurRon controller upgrades that are popular today.
The pack supplies enough current for a SurRon motor rated up to 12 kW of continuous power. Recommended maximum motor power is therefore 12,000 W. Riders who push hard through off-road and enduro terrain benefit most, because the pack holds a stable current under sustained load.
This battery is not suitable for bikes still running the original factory controller. Because of the pack shape, seat risers are required for installation. In addition, the original SurRon battery cover must be removed from the bike.
Technical Specifications
| Nominal voltage | 60 V |
| Maximum voltage | 67.2 V |
| Minimum voltage | 48 V |
| Capacity | 84 Ah |
| Burst maximum power | 16,000 W (16 kW) |
| Recommended max. motor power | 12,000 W (12 kW) |
| Cell manufacturer | Samsung |
| Cell connections | Genuine copper plates |
| Housing | Rugged metal |
| Temperature control | Integrated temperature sensors |
| Monitoring | App (cell group voltage and temperature) |
| Compatible controllers | BAC4000, BAC8000, Torp TC500, EBMX X9000, KO |
| Production | Built to order |
Why Choose This Pack
Most competing packs rely on nickel strips for the cell connections. This one uses genuine copper plates instead. As a result, contact between cells improves and internal resistance drops. Better contact means less imbalance between cell groups and a lower pack temperature.
Lower operating temperature translates directly into a longer service life. Meanwhile, the metal housing keeps the cells protected from rocks, roots and knocks off-road. Samsung cells provide the foundation for consistent output across the full 84 Ah.
Each pack is formed and assembled to order, so units are not held in stock. For production details and lead times, please contact us by phone or write to info@FabiRide.com.
Frequently Asked Questions
Does this battery work with the original SurRon controller?
- No. Connecting this pack to the stock controller is prohibited.
- The bike must first be upgraded to a more powerful controller.
Which controllers is the 60V 84Ah SurRon battery compatible with?
- ASI BAC4000 and ASI BAC8000.
- Torp TC500, EBMX X9000 and KO Moto.
- Other currently popular SurRon controller upgrades also work.
What motor power does this pack support?
- Recommended maximum motor power is 12,000 W (12 kW) continuous.
- Burst maximum output reaches 16,000 W (16 kW).
How much extra range and power does it add?
- Range and power increase by up to three times.
- Capacity of 84 Ah supports long off-road rides.
Does the pack fit under the original SurRon battery cover?
- No. The original SurRon battery cover must be removed.
- Seat risers are required because of the pack shape.
Why copper plates instead of nickel strips?
- Copper plates give better contact and lower resistance.
- Cell group imbalance and operating temperature both drop.
Can I monitor the battery while riding?
- Yes. A Bluetooth app shows overall pack status.
- Voltage and temperature are displayed for each cell group.
Is the pack protected against extreme temperatures?
- Integrated sensors track pack temperature during use.
- Charging is blocked when the pack is too cold or too hot.
This 60V 84Ah SurRon battery turns an upgraded Light Bee into a genuine off-road machine. Samsung cells, copper plate connections and a metal housing work together for stable current under load. Because every unit is built to order, get in touch to confirm your controller setup and current lead time.
