Compact DC-DC step-down converter that converts 30-90 V DC (36/42/48/52/60/72/84 V systems) to a stable 24 V/2 A(48 W). Ideal for 24 V LED lighting, relays, GPS, communication equipment, cameras and other 24 V accessories on e-bikes, scooters or e-motorcycles.
Key benefits
- Wide input: reliable operation from 30 to 90 V DC.
- Stable 24 V output: up to 2 A for sensitive 24 V electronics.
- Versatile applications: lighting, control relays, telemetry, accessories.
- Compact housing: easy installation in limited space.
Specifications
- Type: DC-DC buck (step-down)
- Input voltage: 30-90 V DC (36/42/48/52/60/72/84 V)
- Output voltage: 24 V DC (adjustable)
- Max. Output current: 2 A (~48 W)
- Wires/terminals: Vin+/GND, Vout+/GND (by batch)
- Environment: dry/normal operating conditions*
* For high water/dust resistance, choose an IP67 model.
Customization
- 24 V lighting: LED strips/lights up to ~48 W.
- Control: 24 V relay coils, sirens, valves.
- Electronics: GPS, cameras, communication/telemetry modules, transducer circuits.
Installation tips
- Place a fuse (e.g. 2-3 A) as close to the battery as possible.
- Observe polarity and use the correct cross-section of wires.
- Fix in such a way as to allow sufficient heat dissipation.
- For sensitive loads, an output fuse and additional filtering is recommended.
FAQ
Is it suitable for a 72 V (20s) Li-ion system?
Yes, a fully charged ~84 V is in the 30-90 V range.
Can I power a 24 V LED strip 2 m long?
Yes, as long as the total power does not exceed ~48 W. For higher power, choose a more powerful inverter.
Is it a charger for a 24 V battery?
No. It is a stabiliser (power supply), not a battery charger.
