Voltage converter 20V – 84V to 12V 5A

Voltage converter 20-84 V → 12 V, 5 A (DC-DC, IP67)

Description

A compact and reliable DC-DC converter that delivers a stable 12 V / 5 A power supply from a 20-84 V battery (class 36/48/60/72 V) to your lights, audio, accessories, USB modules, relays and other 12V equipment. IP67 sealed – resistant to dust and temporary immersion.

Key benefits

• Wide input: 20 to 84 V DC – suitable for most e-bike, scooter and e-moto batteries.
• Stable 12 V output: up to 5 A (60 W) for your 12 V peripheral.
• IP67 sealed: safe to use in rain, dust and off-road.
• Versatile: power supply for lights, horn, navigation, cameras, relays/controllers.

Specifications

• Type: step-down DC-DC converter
• Input voltage: 20-84 V DC
• Output voltage: 12 V DC (adjustable)
• Max. Output current: 5 A (~60 W)
• Environmental resilience: IP67
• Transmitter: input (+/-), output 12 V (+/-)

Customization

• E-mobility: 36/48/60/72 V systems for 12 V accessories.
• Lighting: LED/halogen 12 V (not exceeding 60 W).
• Electronics: USB converters, GPS, cameras, chargers, relays.

Installation tips

• Place a fuse (e.g. 3-5 A) as close as possible to the battery at the input.
• Avoid polarity errors; use wires of the correct cross-section.
• Fix to a surface to be cooled; do not conceal in heat retaining housings.
• If you are powering sensitive appliances, you can add a 12 V fuse and additional filtering.

FAQ

Is it suitable for a 72 V (20s) Li-ion system?
Yes – input range up to 84 V. Check that the fully charged voltage is within the limit.

Can I connect 12 V LED strips directly?
Yes, if the total power ≤ 60 W (5 A). A higher load requires a more powerful inverter.

Does the inverter charge a 12 V battery?
No – it’s a stabiliser, not a charger. A 12 V battery needs a suitable charger.

Stable 12 V / 5 A from a 20-84 V battery. IP67, up to 60 W. Suitable for 36/48/60/72 V systems – lights, horn, accessories.
