4pin SurRon charging connector Male/Male Connector

OEM type 4 pin Male charging connector for mounting on the end of the charger/charging cable. Compatible with Sur-Ron Light Bee X / L1E and other models with 4-pin charging socket on motorcycle/battery side (Female). Ensures reliable contact, low transient resistance and safe charging.

Customization

• For the charger/charging cable, a connector plug that plugs into the 4-pin socket on the motorcycle.
• For servicing, repairs, “upgrades ” – when you need to make or replace a charging cable.
• Adapters – for switching from universal chargers to the SurRon 4-pin standard.

Benefits

• OEM compatibility with SurRon 4-pin charging port.
• Robust mechanics – resistant to vibration and frequent switching.
• Clear polarity – reduces the risk of misconnection.
• Low contact resistance – more stable charging, lower losses.

Specifications

• Type: 4-pin Male charging connector
• Installation: on the side of the charger/charging cable
• Number of contacts: 4
• Wire fixing: soldering or crimping (according to nozzles)
• Quantity: 1 pc. (Motorcycle Side Female – purchased separately)

Installation tips

• Before soldering , check the polarity according to the 4-pin diagram of your charger and SurRon.
• Use a suitable cross-section of cable and apply heat-shrink insulation.
• After connecting, check the voltage and the correct pinout with a multimeter before connecting to the motorcycle.

FAQ

Does the Light Bee X and L1E fit?
Yes, it is a SurRon 4-pin Male connector for the charger.

Is this connector for a battery?
No. The 4-pin Female connector is used on the battery/motorcycle side.

Can I use it with a fast charger?
Yes, as long as the charger’s voltage/amperage and the cross-section of the wires comply with the manufacturer’s requirements.
