XT90 Male/Male Connector

Reliable XT90 Male DC connector for high currents in e-bikes, scooters, e-motorcycles, RC and DIY projects. The large contact area ensures low transient resistance and stable operation even under high loads. The key geometry protects against false polarity.

Customization

• For battery → controller power line
• Charging cables/adapters (according to charger specifications)
• Upgrade solutions (Sur-Ron, Talaria, e-MTB, e-moto, RC)

Benefits

• High current capacity – ~90 A continuous*
• Robust construction – resistant to vibration and frequent connections
• Easy installation – deep soldering “cups”, convenient for fitting thermo couplings
• Secure enrolment – a key form before contact

* The actual allowable load depends on the cross-section of the wire, the quality of the cooling and the soldering.

Specifications

• Type: XT90 Male, 2 pin DC
• Rated current: ~90 A (continuous), higher transient peaks are possible depending on the installation
• Recommended wire: 10-12 AWG (select according to current and length)
• Contacts: gold plated copper alloy
• Housing: heat-resistant PA/nylon material
• Quantity: 1 pc. (Paired Female connector sold separately)

Installation tips

• Observe polarity (+ red / – black).
• Use a powerful soldering iron and short heating times; apply heat-shrink after soldering.
• Leave the tension loop in the cable to avoid breaking the solder.
• If you need anti-spark functionality, choose the XT90-S pair (anti-spark version).

FAQ

Is it an anti-spark connector?
No. Anti-spark function is available on the XT90-S version (used in pair with the corresponding Female).

Is it suitable for fast charging?
Yes, if the charger current and the cross-section of the wires meet the requirements.

How is XT90 different from XT60?
XT90 is designed for higher currents (larger contact area), resulting in lower losses at high loads.
