A compact and powerful step-up (boost) converter that allows to raise the voltage from 9-48 V to 10-50 V. Suitable for e-bike/scooter projects, LEDs, inverters, when you need a stable higher voltage from a lower source.
Key benefits
- Wide range: 9-48 V input → 10-50 V output.
- High power: up to 10 A output current (depending on Vout/Vin ratio and cooling).
- Versatile applications: lights, controller peripherals, test stations, DIY.
Specifications
- Type: DC-DC Step-UP (Boost)
- Input voltage: 9-48 V DC
- Output voltage: 10-50 V DC (adjustable)
- Max. Output current: 10 A (with adequate cooling)
- Protection: batch/module dependent – fuse on input recommended
- Cooling: passive/active (load-based)
Customization
- E-mobility: additional accessories/lights can be powered from a lower battery voltage.
- LED/Electronics: stable higher Vout from 12/24/36/48 V sources.
- Lab/DIY: a regulated source for tests and prototypes.
Tips for use
- First set the output voltage (potentiometer) without load.
- Observe the power balance:
Pin ≈ Pout / efektyvumas→ as Vout increases, the input current increases. - At high power, ensure cooling (radiator/airflow).
- Install a fuse at the input and capacitors at loads susceptible to surges.
- Do not confuse polarity; use wires of the correct cross-section.
FAQ
Can you get 48 V from 12 V?
Yes, if the power reserve and cooling are sufficient. The input current will be several times higher than the output current divided by the ratio and efficiency.
Does the inverter stabilise the voltage?
Yes – it’s an adjustable boost; set the desired Vout with no load and then connect the load.
Is it safe to power LED strips?
Yes, as long as you respect the Vout and current limits; for LEDs it is advisable to have a current limiter or a separate LED driver.
